At Online Lighting we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Dimensions
Cut Out DimensionsØ205 mm
Depth220 mm
Height30 mm
Width220 mm
Certificates and Stamps
Technical Specifications
Technical Information
Measures in degrees how light spreads from the source. A wide angle covers more area, while a narrow one is ideal for highlighting details.
Beam Angle120º
Quality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
CertificatesRoHS, CE, TÜV
Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
Colour Rendering Index80
Defines the light tone, from warm white to cool white, measured in Kelvin (K).
Colour Temperature4000K
DimmableNo
Driver Intensity650 mA
Voltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
Driver Tension25 V-42 V
Electrical Insulation ClassII
Fitting MaterialAluminium, PC
Frequency50-60 Hz
Low-glare products offer more comfortable lighting, suitable for extended use.
Glare FactorUGR 19
Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
Hours40.000 hours
Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
IK ProtectionIK05
InstallationRecessed
The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
IP RatingIP44
Light ColourNeutral White
Lumens3600 lm
Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
Luminous Efficiency120 lm/W
Minimum and maximum voltage fluctuation that the product can withstand momentarily.
Nominal Voltage180-265V AC
Power Factor0.96
ShapeSquare
Voltage level required for the product to function correctly.
